RTUE60-XL INA

Name: RTUE60-XL INA
Brand: INA

€ 159,97 ex VAT

€ 193,56 incl. VAT

€ 159,97 ex VAT

	Guaranteed same day shipment on orders placed before 17.00h (CET)
	This product is available from stock
	Worldwide shipping from the Netherlands
	30 days return policy
	Track your order through Track & Trace

RTUE60-XL INA

Housing unit

Stock	24 pcs available
Brand	INA
Article number	RTUE60-XL INA
Inside diameter	60mm
Outside diameter	186mm
Width	60mm

Product description

The RTUE60-XL INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Email us at: help@247industries.com Response within 24h

Downloads and links

Similar to: RTUE60-XL INA

Loading similair products

Product specifications

Inside diameter 60mm
Outside diameter 186mm
Width 60mm

All dimensions

Inner (d) MM 60
Outer (D) MM 186
Width (B) MM 60
Inner (d) Inch 2.3622
Outer (D) Inch 7.3228
Width (B) Inch 2.3622
Height (H) mm 146
Length total (L) mm 186

Suffix description

XL X-Life

Technical details

Availability 24 pcs
Brand INA
Item number RTUE60-XL INA
Also known as 0008277380000
RTUE60
EAN 4012802793574
Category Housing and Bearing (assembly)

Weight and Dimensions

Weight (kg) 4.84

Product Properties

Seal 2F - Standard Seal for Y-bearings
Lubrication Standard Lubrication
Special Treatment No Special Treatment

Data from Schaeffler (medias)

ECLASS number 23-05-16-03
ECLASS2 number 23-05-16-03
Medias description Take-up housing units RTUE, cast iron housing, radial insert ball bearing with eccentric locking collar, R seals
