RTUE65-214-XL INA

Housing unit

Stock
8 pcs in stock and ready for shipment
Brand INA
Article number RTUE65-214-XL INA
Inside diameter 65mm
Outside diameter 214mm
Width 70mm
Product description

The RTUE65-214-XL INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Read more Show less
Help with this product

Downloads and links

Similar to: RTUE65-214-XL INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 65
  2. Outer (D) MM 214
  3. Width (B) MM 70
  4. Inner (d) Inch 2.5591
  5. Outer (D) Inch 8.4252
  6. Width (B) Inch 2.7559
  7. Height (H) mm 166
  8. Length total (L) mm 214

Suffix description

  1. XL X-Life

Technical details

  1. Availability 8 pcs
  2. Brand INA
  3. Item number RTUE65-214-XL INA
  4. Also known as 0008775300000
    GE65-214-KRRB+GG.TUE13/14
    GE65KRRB + TUE13/14
  5. EAN 4012802795196
  6. Category Housing and Bearing (assembly)

Weight and Dimensions

  1. Weight (kg) 7.46

Product Properties

  1. Seal 2F - Standard Seal for Y-bearings
  2. Lubrication Standard Lubrication
  3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

  1. ECLASS number 23-05-16-03
  2. ECLASS2 number 23-05-16-03
  3. Medias description Take-up housing units RTUE, cast iron housing, radial insert ball bearing with eccentric locking collar, R seals
