RWU25-E-L-V2-G3 INA

All dimensions

1. Inner (d) MM 23
2. Outer (D) MM 70
3. Width (B) MM 107
4. Inner (d) Inch 0.9055
5. Outer (D) Inch 2.7559
6. Width (B) Inch 4.2126
7. Width carriage (B) mm 70
8. Overall length carriage (L) mm 107

Suffix description

1. E Version
2. L Long Carriage
3. V2 Preload Class 2
4. G3 Precision Class 3

Technical details

1. Availability 4 pcs
2. Brand INA
3. Item number RWU25-E-L-V2-G3 INA
4. Also known as 0649925431340

5. EAN 4054368317702
6. Category Linear Plain Bearing Unit

Weight and Dimensions

1. Weight (kg) 0.91

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Dynamic load rating (C) 33500
2. Dynamic load rating (C 0) 82000
3. Static moment rating about X axis (M 0x) 440
4. Static moment rating about Y axis (M 0y) 1200
5. Static moment rating about Z axis (M 0z) 1080
