RWU25-E-V3-G2 INA

All dimensions

1. Inner (d) MM 23
2. Outer (D) MM 70
3. Width (B) MM 91
4. Inner (d) Inch 0.9055
5. Outer (D) Inch 2.7559
6. Width (B) Inch 3.5827
7. Width carriage (B) mm 70
8. Overall length carriage (L) mm 91

Suffix description

1. E Version
2. V3 Preload Class 3
3. G2 Precision Class 2

Technical details

1. Availability 10 pcs
2. Brand INA
3. Item number RWU25-E-V3-G2 INA
4. Also known as 0649922411430
   RWU25-E-G2-V3

5. EAN 4054364295875
6. Category Linear Plain Bearing Unit

Weight and Dimensions

1. Weight (kg) 0.74

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Dynamic load rating (C) 28000
2. Dynamic load rating (C 0) 65000
3. Static moment rating about X axis (M 0x) 350
4. Static moment rating about Y axis (M 0y) 760
5. Static moment rating about Z axis (M 0z) 680
6. ECLASS number 23-30-04-90
7. ECLASS2 number 23-30-04-90

Downloads and links

1. Link to manufacturer Link to manufacturer
