SAKB12F SKF

Rod end

Stock
14 pcs available
Brand SKF
Article number SAKB12F SKF
Inside diameter 12mm
Outside diameter 34mm
Width 16mm
Product description

The SAKB12F SKF is a rod end. Rod ends consist of a housing with integral shank and a spherical plain bearing. This plain bearing is composed of an inner and outer ring without rolling elements. Rod ends are often mounted on the end of hydraulic or pneumatic cylinders. They are also used to connect two shafts. Rod ends can accommodate misalignment, and they support radial forces in a tensile or compressive direction.

The SAKB12F SKF has a spherical plain bearing with a steel-on-PTFE sliding contact, making it maintenance-free. PTFE is a special plastic. During the run-in period of these plain bearings, particles of PTFE are deposited on the opposite running surface. They fill in the small irregularities of the inner ring surface, creating a smooth surface. As a result, the components fit each other perfectly.

Read more Show less
Help with this product

Similar to: SAKB12F SKF

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 12
  2. Outer (D) MM 34
  3. Width (B) MM 16
  4. Inner (d) Inch 0.4724
  5. Outer (D) Inch 1.3386
  6. Width (B) Inch 0.6299

Suffix description

  1. F Steel/PTFE Composite

Technical details

  1. Availability 14 pcs
  2. Brand SKF
  3. Item number SAKB12F SKF
  4. Also known as DSA12T/K
    GAKFR12-PW-A
    GASW12
    KA12D
  5. EAN 7316577079480
  6. Category Rod End

Weight and Dimensions

  1. Weight (kg) 0.1

Product Properties

  1. Seal No Seal
  2. Contact Material Steel on PTFE
Show all details Show less
