SAKB5F SKF

Rod end

Stock
17 pcs available
Brand SKF
Article number SAKB5F SKF
Inside diameter 5mm
Outside diameter 18mm
Width 8mm
Product description

The SAKB5F SKF is a rod end. Rod ends consist of a housing with integral shank and a spherical plain bearing. This plain bearing is composed of an inner and outer ring without rolling elements. Rod ends are often mounted on the end of hydraulic or pneumatic cylinders. They are also used to connect two shafts. Rod ends can accommodate misalignment, and they support radial forces in a tensile or compressive direction.

The SAKB5F SKF has a spherical plain bearing with a steel-on-PTFE sliding contact, making it maintenance-free. PTFE is a special plastic. During the run-in period of these plain bearings, particles of PTFE are deposited on the opposite running surface. They fill in the small irregularities of the inner ring surface, creating a smooth surface. As a result, the components fit each other perfectly.

Read more Show less
Help with this product

Similar to: SAKB5F SKF

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 5
  2. Outer (D) MM 18
  3. Width (B) MM 8
  4. Inner (d) Inch 0.1969
  5. Outer (D) Inch 0.7087
  6. Width (B) Inch 0.315

Suffix description

  1. F Steel/PTFE Composite

Technical details

  1. Availability 17 pcs
  2. Brand SKF
  3. Item number SAKB5F SKF
  4. Also known as BEM05-20-501
    DSA05T/K
    GAKFR5PW
    SA5T/K
  5. EAN 7316577003706
  6. Category Rod End

Weight and Dimensions

  1. Weight (kg) 0.013

Product Properties

  1. Seal No Seal
  2. Contact Material Steel on PTFE
Show all details Show less
