SIL20C SKF

Rod end

Stock
1 pc in stock and ready for shipment
Brand SKF
Article number SIL20C SKF
Inside diameter 20mm
Outside diameter 54mm
Width 16mm
Product description

The SIL20C SKF is a rod end. Rod ends consist of a housing with integral shank and a spherical plain bearing. This plain bearing is composed of an inner and outer ring without rolling elements. Rod ends are often mounted on the end of hydraulic or pneumatic cylinders. They are also used to connect two shafts. Rod ends can accommodate misalignment, and they support radial forces in a tensile or compressive direction.

The SIL20C SKF has a spherical plain bearing with a steel-on-PTFE sliding contact, making it maintenance-free. PTFE is a special plastic. During the run-in period of these plain bearings, particles of PTFE are deposited on the opposite running surface. They fill in the small irregularities of the inner ring surface, creating a smooth surface. As a result, the components fit each other perfectly.

Read more Show less
Help with this product

Similar to: SIL20C SKF

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 20
  2. Outer (D) MM 54
  3. Width (B) MM 16
  4. Inner (d) Inch 0.7874
  5. Outer (D) Inch 2.126
  6. Width (B) Inch 0.6299

Suffix description

  1. C Steel/PTFE Sintered Bronze Sliding Contact Surface Combination

Technical details

  1. Availability 1 pc
  2. Brand SKF
  3. Item number SIL20C SKF
  4. EAN 7316577003591
  5. Category Rod End

Weight and Dimensions

  1. Weight (kg) 0.32

Product Properties

  1. Seal No Seal
  2. Contact Material Steel on PTFE
