T7FC060T80/QCL7CDTC10 SKF

All dimensions

1. Inner (d) MM 60
2. Outer (D) MM 125
3. Width (B) MM 80
4. Inner (d) Inch 2.3622
5. Outer (D) Inch 4.9213
6. Width (B) Inch 3.1496

Suffix description

1. T80 T, Followed By A Figure, Identifies The Total Width Of Bearing Pairs Arranged Back-To-Back Or In Tandem
2. QCL7C High-Performance Design For Pinion Bearing Arrangements
3. DT Machined Bearing Pair Arranged In Tandem. A Figure Combination Immediately Following The DT Identifies The Design Of The Intermediate Rings
4. C10 Axial Clearance in µm

Technical details

1. Availability 1 pc
2. Brand SKF
3. Item number T7FC060T80/QCL7CDTC10 SKF
4. EAN 7316570904277
5. Category Tapered Roller Bearing Single Row (paired metric)

Weight and Dimensions

1. Weight (kg) 4.05

Product Properties

1. Tapered Roller Pair Internal Play DT-standard Paired Metric T-ar
