TCJ60-XL-N INA

Housing unit

Stock
16 pcs available for shipment on Mon 2 Dec
Brand INA
Article number TCJ60-XL-N INA
Inside diameter 60mm
Outside diameter 175mm
Width 80,9mm
Product description

The TCJ60-XL-N INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Read more Show less
Help with this product

Downloads and links

Similar to: TCJ60-XL-N INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 60
  2. Outer (D) MM 175
  3. Width (B) MM 80,9
  4. Inner (d) Inch 2.3622
  5. Outer (D) Inch 6.8898
  6. Width (B) Inch 3.185
  7. Flange width (L) mm 175
  8. Total height unit (U) mm 80,9

Suffix description

  1. XL X-Life
  2. N Cast Iron Housing With Undercut Slot For End Caps

Technical details

  1. Availability 16 pcs on Mon 2 Dec
  2. Brand INA
  3. Item number TCJ60-XL-N INA
  4. Also known as 0947479110000
    NIP DIN71412-A R 1/8
    NIP DIN71412-B R 1/8
    NIP DIN71412-C R 1/8
    TCJ60-N
  5. EAN 4054372939099
  6. Category Housing and Bearing (assembly)

Weight and Dimensions

  1. Weight (kg) 4.54

Product Properties

  1. Seal 2T - Two T-seals
  2. Lubrication Standard Lubrication
  3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

  1. Basic static load rating, radial (C 0r) 36000

Downloads and links

  1. X-life brochure X-life brochure
  2. Link to manufacturer Link to manufacturer
