THE50-XL INA

Housing unit

Stock	8 pcs in stock and ready for shipment
Brand	INA
Article number	THE50-XL INA
Inside diameter	50mm
Outside diameter	145mm
Width	110mm

Product description

The THE50-XL INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Email us at: help@247industries.com Response within 24h

Downloads and links

Similar to: THE50-XL INA

Loading similair products

Product specifications

Inside diameter 50mm
Outside diameter 145mm
Width 110mm

All dimensions

Inner (d) MM 50
Outer (D) MM 145
Width (B) MM 110
Inner (d) Inch 1.9685
Outer (D) Inch 5.7087
Width (B) Inch 4.3307
Length total (L) mm 145
Housing total width (M) mm 110
Width housing (A 2) mm 40

Suffix description

XL X-Life

Technical details

Availability 8 pcs
Brand INA
Item number THE50-XL INA
Also known as 0008573430000
THE50
EAN 4012802798654
Category Housing and Bearing (assembly)

Weight and Dimensions

Weight (kg) 2.08

Product Properties

Seal 2T - Two T-seals
Lubrication Standard Lubrication
Special Treatment No Special Treatment

Data from Schaeffler (medias)

ECLASS number 23-05-16-03
ECLASS2 number 23-05-16-03
Medias description Take-up housing units THE, cast iron housing, radial insert ball bearing with eccentric locking collar, T seals
