YRT50-C INA

All dimensions

1. Inner (d) MM 50
2. Outer (D) MM 126
3. Width (B) MM 30
4. Inner (d) Inch 1.9685
5. Outer (D) Inch 4.9606
6. Width (B) Inch 1.1811
7. Height (H) mm 30

Suffix description

1. C Unknown

Technical details

1. Availability 3 pcs
2. Brand INA
3. Item number YRT50-C INA
4. Also known as 0502111290000
   YRTC50-C
   YRTC50-XL-C

5. EAN 4047643206228
6. Category Specials

Weight and Dimensions

1. Weight (kg) 1.6

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 49500
2. Radial Dynamic Load Rating Cr (N) 28500
3. Axial Static Load Rating C0a (N) 280000
4. Axial Dynamic Load Rating Ca (N) 56000
5. Limiting speed (n G) 440
6. ECLASS number 23-05-12-04
7. ECLASS2 number 23-05-12-04
8. Medias description Axial/radial bearings YRT, double direction, for screw mounting

Downloads and links

1. Link to manufacturer Link to manufacturer
