3GGP082324-ASB ABB

80-4P 0,75kW 230/400V B3 CI

Stock
not in stock
Brand ABB
Article number 3GGP082324-ASB ABB
Rated power 0.75kW
Mounting B3 / 1M1001 (foot)
Frequency 50 Hz
Speed (RPM) 1500 / 4-Poles
Product description
Read more Show less
Help with this product

Similar to: 3GGP082324-ASB ABB

Loading similair products

Product specifications

Technical details

  1. Availability 0 pcs
  2. Brand ABB
  3. Item number 3GGP082324-ASB ABB
  4. Category Atex Motors

Weight and Dimensions

  1. Weight (kg) 21

Product Properties

  1. Rated power (kW) 0.75
  2. Speed at 50Hz (rpm) 1500 / 4-Poles
  3. Frequency 50 Hz
  4. Energy efficiency IE2 = High = EFF1
  5. Mounting B3 / 1M1001 (foot)
  6. Brake No Brake
  7. IP Class IP55
  8. Explosion safety (Atex) Zone 2
  9. IEC Framesize 80

Detailed Product Properties

  1. Voltage 220-230VD / 380-400VY
  2. IEC Framesize 80
  3. Shaft diameter (mm) 19
  4. Housing material Cast Iron
  5. AC/DC AC
  6. Standard IEC
  7. Shaft height IEC in JDE 080
  8. Shaft length (mm) 40
  9. Shaft key width (mm) 6
  10. Shaft key length (mm) 32
  11. Thread shaft bore M6
  12. Shaft height, B3 mounted (mm) 80
  13. Width foot holes, B3 mounted (mm) 125
  14. Length foot holes, B3 mounted (mm) 100
  15. Diameter foot holes (mm) 9.5
  16. Outer diameter flange B5/V1/B35/V3 (mm) 200
  17. Spigot B5/V1/B35/V3 (mm) 130
  18. Pitch circle diameter B5/V1/B35/V3 (mm) 165
  19. Number of flange holes 4
  20. Diameter flange holes B5/V1/B35/V3 (mm) 12
  21. Pitch circle diameter B14/B34/V18/V19 (mm) 100
  22. Thread flange holes B14/B34/V18/V19 M6
  23. Outer diameter flange B14/B34/V18/V19 (mm) 120
  24. Spigot B14/B34/V18/V19 (mm) 80
