CMRV50-71B5I15 Cemer

€ 125,34 ex VAT
€ 151,67 incl. VAT
€ 151,67 incl. VAT
€ 125,34 ex VAT
Guaranteed same day shipment on orders placed before 17.00h (CET)
This product is available from stock
Worldwide shipping from the Netherlands
30 days return policy
Track your order through Track & Trace
iDeal, Mastercard, Visa, PayPal

CMRV50-71B5I15 Cemer

Wormgear 71-B5 i=15

Stock
7 pcs in stock and ready for shipment
Brand Cemer
Article number CMRV50-71B5I15 Cemer
Mounting B5 (outer flange)
Product description
Read more Show less
Help with this product

Similar to: CMRV50-71B5I15 Cemer

Loading similair products

Product specifications

Technical details

  1. Availability 7 pcs
  2. Brand Cemer
  3. Item number CMRV50-71B5I15 Cemer
  4. Category Gearboxes

Weight and Dimensions

  1. Weight (kg) 3.7

Product Properties

  1. Mounting B5 (outer flange)
  2. Gear ratio i = n1/n2 15
  3. IEC Framesize 71

Detailed Product Properties

  1. IEC Framesize 71
  2. Shaft diameter (mm) 14
  3. Shaft height IEC in JDE 071
  4. Shaft length (mm) 30
  5. Shaft key width (mm) 5
  6. Shaft key length (mm) 22
  7. Thread shaft bore M5
  8. Shaft height, B3 mounted (mm) 71
  9. Width foot holes, B3 mounted (mm) 112
  10. Length foot holes, B3 mounted (mm) 90
  11. Diameter foot holes (mm) 7
  12. Outer diameter flange B5/V1/B35/V3 (mm) 160
  13. Spigot B5/V1/B35/V3 (mm) 110
  14. Pitch circle diameter B5/V1/B35/V3 (mm) 130
  15. Number of flange holes 4
  16. Diameter flange holes B5/V1/B35/V3 (mm) 10
  17. Pitch circle diameter B14/B34/V18/V19 (mm) 85
  18. Thread flange holes B14/B34/V18/V19 M6
  19. Outer diameter flange B14/B34/V18/V19 (mm) 105
  20. Spigot B14/B34/V18/V19 (mm) 70
Show all details Show less
