SRT050701424B3-63B14 Varvel

Wormgear 63-B14 i=70

Stock
2 pcs in stock and ready for shipment
Brand Varvel
Article number SRT050701424B3-63B14 Varvel
Mounting B14 (inner flange)
Product description
Read more Show less
Help with this product

Similar to: SRT050701424B3-63B14 Varvel

Loading similair products

Product specifications

Technical details

  1. Availability 2 pcs
  2. Brand Varvel
  3. Item number SRT050701424B3-63B14 Varvel
  4. Category Gearboxes

Weight and Dimensions

  1. Weight (kg) 3.75

Product Properties

  1. Mounting B14 (inner flange)
  2. Gear ratio i = n1/n2 70
  3. IEC Framesize 63

Detailed Product Properties

  1. IEC Framesize 63
  2. Shaft diameter (mm) 11
  3. Shaft height IEC in JDE 063
  4. Shaft length (mm) 23
  5. Shaft key width (mm) 4
  6. Shaft key length (mm) 16
  7. Thread shaft bore M4
  8. Shaft height, B3 mounted (mm) 63
  9. Width foot holes, B3 mounted (mm) 100
  10. Length foot holes, B3 mounted (mm) 80
  11. Diameter foot holes (mm) 7
  12. Outer diameter flange B5/V1/B35/V3 (mm) 140
  13. Spigot B5/V1/B35/V3 (mm) 95
  14. Pitch circle diameter B5/V1/B35/V3 (mm) 115
  15. Number of flange holes 4
  16. Diameter flange holes B5/V1/B35/V3 (mm) 10
  17. Pitch circle diameter B14/B34/V18/V19 (mm) 75
  18. Thread flange holes B14/B34/V18/V19 M5
  19. Outer diameter flange B14/B34/V18/V19 (mm) 90
  20. Spigot B14/B34/V18/V19 (mm) 60
