CSK30P C5 Stieber

Afmetingen

1. Binnenmaat (d) mm 30
2. Buitenmaat (D) mm 62
3. Breedte (B) mm 16

Suffix-omschrijving

1. P Features A Keyway On The Inner Race. For This Reason It Can Be Keyed To A Shaft To K6 Tolerance. The Outer Race Must Still Be Pressed Into A Rigid Housing To N6 Tolerance
2. C5 Bearing Internal Clearance Greater Than C4

Technische specificaties

1. Beschikbaarheid 0 stuks
2. Merk Stieber
3. Item number CSK30P C5 Stieber
4. Category Koppeling

Gewicht en afmetingen

1. Gewicht (kg) 0.224
