GAKL6-PW-A INA

Afmetingen

1. Binnenmaat (d) mm 6
2. Buitenmaat (D) mm 20
3. Breedte (B) mm 9
4. Binnenmaat (d) inch 0.2362
5. Buitenmaat (D) inch 0.7874
6. Breedte (B) inch 0.3543
7. Buitendiameter lager (D) mm 16
8. Buitenoogdiameter (d 2) mm 20
9. Breedte binnenring (B) mm 9
10. Totale lengte uitwendige draadstang (l 2) mm 46

Suffix-omschrijving

1. PW Sliding Contact Surface Steel/PTFE (Polyetrafluoroethylene) Bronze Film
2. A The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)

Technische specificaties

1. Beschikbaarheid 38 stuks
2. Merk INA
3. Item number GAKL6-PW-A INA
4. Also known as 0066388990000

5. EAN 4012802527728
6. Category Stangkop

Gewicht en afmetingen

1. Gewicht (kg) 0.019

Producteigenschappen

1. Afdichting Geen afdichting
2. Contactmateriaal Staal op PTFE

Data van Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 6930
2. Radial Dynamic Load Rating Cr (N) 7750
3. Basis statische radiale belasting (C 0r) "6930.0000"
4. ECLASS number 23-05-01-05
5. ECLASS2 number 23-05-01-05
6. Medias omschrijving Rod end GAKL..-PW, external threads, maintenance-free

Downloads en links

1. Link to manufacturer Link to manufacturer
