KN30-B INA

Afmetingen

1. Binnenmaat (d) mm 30
2. Buitenmaat (D) mm 47
3. Breedte (B) mm 68
4. Binnenmaat (d) inch 1.1811
5. Buitenmaat (D) inch 1.8504
6. Breedte (B) inch 2.6772
7. Lengte (L) mm 68

Suffix-omschrijving

1. B Guideways And Carriages May Only Be Combined With Each Other Within The Same Accuracy And Interchangeability Class, So A Can Only Be Combined With A, And B Can Only Be Combined With B

Technische specificaties

1. Beschikbaarheid 9 stuks
2. Merk INA
3. Item number KN30-B INA
4. Also known as 0296806890000
   KN3068
   LBCD30A
   LMES30
   R0670-030-00
   SPM30
   TK30

5. EAN 4054362444800
6. Category Lineairkogellager

Gewicht en afmetingen

1. Gewicht (kg) 0.13

Producteigenschappen

1. Afdichting Geen afdichting

Data van Schaeffler (medias)

1. Dynamische belastbaarheid dyn. (C min) 3750
2. Dynamische belastbaarheid stat. (C 0 min) 2850
3. Dynamische belastbaarheid stat. (C 0 max) 3650
4. ECLASS number 23-30-03-01
5. ECLASS2 number 23-30-03-01
6. Medias omschrijving Linear ball bearings KN..-B, Lightweight range, closed design, with relubrication facility, adjustable angle

Downloads en links

1. Link to manufacturer Link to manufacturer
