KN30-B-PP INA

Afmetingen

1. Binnenmaat (d) mm 30
2. Buitenmaat (D) mm 47
3. Breedte (B) mm 68
4. Binnenmaat (d) inch 1.1811
5. Buitenmaat (D) inch 1.8504
6. Breedte (B) inch 2.6772
7. Lengte (L) mm 68

Suffix-omschrijving

1. B Guideways And Carriages May Only Be Combined With Each Other Within The Same Accuracy And Interchangeability Class, So A Can Only Be Combined With A, And B Can Only Be Combined With B
2. PP Lip Seal On Both Sides Of Bearing

Technische specificaties

1. Beschikbaarheid 34 stuks
2. Merk INA
3. Item number KN30-B-PP INA
4. Also known as 0244623140000

5. EAN 4012802281255
6. Category Lineairkogellager

Gewicht en afmetingen

1. Gewicht (kg) 0.13

Producteigenschappen

1. Afdichting 2L - LS-seal at Both Sides

Data van Schaeffler (medias)

1. Dynamische belastbaarheid dyn. (C min) 3750
2. Dynamische belastbaarheid stat. (C 0 min) 2850
3. Dynamische belastbaarheid stat. (C 0 max) 3650
4. ECLASS number 23-30-03-01
5. ECLASS2 number 23-30-03-01
6. Medias omschrijving Linear ball bearings KN..-B-PP, Lightweight range, closed design, sealed on all sides, with relubrication facility, adjustable angle
