SL184926-A-C3 INA

Afmetingen

1. Binnenmaat (d) mm 130
2. Buitenmaat (D) mm 180
3. Breedte (B) mm 50
4. Binnenmaat (d) inch 5.1181
5. Buitenmaat (D) inch 7.0866
6. Breedte (B) inch 1.9685
7. Breedte (b) mm 50

Suffix-omschrijving

1. A The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
2. C3 Internal Clearance Larger Than Normal

Technische specificaties

1. Beschikbaarheid 3 stuks
2. Merk INA
3. Item number SL184926-A-C3 INA
4. Also known as 0001249230030
   NNCF4926V

5. EAN 4054364130459
6. Category Tweerijig cilinderrollager

Gewicht en afmetingen

1. Gewicht (kg) 3.9

Producteigenschappen

1. Boring C - cilindrische boring
2. Afdichting Geen afdichting
3. Type kooi FC - volrollig, geen kooi
4. Externe aanpassing Geen Externe Aanpassing
5. Interne radiale speling C3 interne speling (hoger dan Cn)
6. Precisie Standaardprecisie
7. Warmtestabilisatie Geen warmtestabilisatie - temperaturen tot 120 °C

Data van Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 510000
2. Radial Dynamic Load Rating Cr (N) 260000
3. Basis statische radiale belasting (C 0r) "510000.0000"
4. Grenstoerental (n G) 2090
5. Referentiesnelheid (n ϑr) 1500
6. ECLASS number 23-05-09-01
7. ECLASS2 number 23-05-09-01
8. Medias omschrijving Cylindrical roller bearing SL18..-A, full complement roller set, two-row, semi-locating bearing, 1 rib on outer ring, 3 ribs on inner ring, type SL18

Downloads en links

1. Link to manufacturer Link to manufacturer
