SL185026-A-BR-C3 INA

Afmetingen

1. Breedte (b) mm 95

Suffix-omschrijving

1. A The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
2. BR Black Finished, Factory-Applied Durotect® B Black-Oxide Coating. Durotect B Improves Run-In Behavior And Energy Efficiency While Reducing Surface-Induced Damage To The Bearing, Burnished Race
3. C3 Internal Clearance Larger Than Normal

Technische specificaties

1. Beschikbaarheid 4 stuks
2. Merk INA
3. Item number SL185026-A-BR-C3 INA
4. Also known as 0829767910030

5. EAN 4054364382438
6. Category Tweerijig cilinderrollager

Gewicht en afmetingen

1. Gewicht (kg) 10.2

Producteigenschappen

1. Boring C - cilindrische boring
2. Afdichting Geen afdichting
3. Type kooi FC - volrollig, geen kooi
4. Externe aanpassing Geen Externe Aanpassing
5. Interne radiale speling C3 interne speling (hoger dan Cn)
6. Precisie BR - Black Finishing
7. Warmtestabilisatie Geen warmtestabilisatie - temperaturen tot 120 °C

Data van Schaeffler (medias)

1. Basis statische radiale belasting (C 0r) 1210000
2. Grenstoerental (n G) 1990
3. Referentiesnelheid (n ϑr) 1340
4. ECLASS number 23-05-09-01
5. ECLASS2 number 23-05-09-01
